Product information “SRT Coreless HV 18.0kg/0.10sec @7.4V”
SRT-Racing – Servos for Profis!
Features
- Successor to the CH6020 servo
- Supports multiple high-speed modes now: SR, SFR, SUR, SXR
- Coreless motor
- Incredible efficiency and low power consumption
- 330Hz working frequence
- Superior holding and speed
- Metal gear
Technical Specifications
| Voltage: | 6.0V | 7.4V | 8.4V |
| Operating Speed: | 0.12 sec/60° | 0.10 sec/60° | 0.09 sec/60° |
| Torque: | 14.0 kgcm | 18.0 kgcm | 20.0 kgcm |
| Motor: | Coreless | ||
| Gear: | Titanium / Aluminium | ||
| Typ: | Digital | ||
| Frequence: | 330Hz | ||
| Ball Bearing: |
Yes, dual
|
||
| Dimension: | 41.3 x 20.5 x 38.3mm | ||
| Weight: | 69.0g | ||
| Horn Gear Spline: | n.A. | ||
| Application: | 1/10 On-Road and 1/8 Off-Road, larger airplanes and jets | ||
Delivery
1x CH620S Servo
1x Sticker
